Port configuration | 1×4 | 1×8 | 1×16 | 1×32 | 1×64 | |
Optic fiber type | G652D、G657A1、G657A2 | |||||
Operation wavelength（nm) | ||||||
Insertion loss(dB) | max(A/P) | 7.4/7.2 | 10.7/10.5 | 13.9/13.7 | 16.9/16.5 | 21.0 |
Uniformity(dB) | max | 0.6 | 0.8 | 1.2 | 1.7 | 2.5 |
Return loss(dB) | min | 55 | 55 | 55 | 55 | 55 |
PDL(dB) | max | 0.2 | 0.3 | 0.3 | 0.3 | 0.4 |
Directionality(dB） | min | 55 | 55 | 55 | 55 | 55 |
WDL（dB) | max | 1.0 | 1.0 | 1.0 | 1.0 | 1.0 |
TDL(dB) | max | 0.5 | 0.5 | 0.8 | 0.8 | 1.0 |
Working temperature(℃) | -40 to +85 | |||||
Storage temperature (℃) | -40 to +85 | |||||
Encapsulation dimension | 40×4×4 | 40×4×4 | 40×4×4 | 50×7×4 | 60×12×4 | |
FTTX
CATV
Local area network（LAN）
Wide area network（WAN）
A/D passive optic network
Low insertion loss Low PDL
High return loss
Wide operation wavelength Excellent uniformity
Various kinds of port configuration
