Connector

MPO (Female)

LC

Operation Temperature

-40°C ~ +80°C

Storage Temperature

-40°C ~ +85°C

Insertion Loss

  SM: ≤ 0.75dB (standard value),

  ≤0.35dB (typical value);

  MM:≤ 0.50dB (standard value),

  ≤0.35dB (typical value);

  SM:≤ 0.2dB;

  MM:≤ 0.2dB;

Return Loss

SM:≥60dB;

MM:≥35dB;

SM:≥60dB;

MM:≥35dB;

The MPO end type

Male: with guide pin; Female: without guide pin

Fiber count

8,12&24 MT fiber

The other end of the connector type

MPO-female , MPO-male , FC , SC , ST , MU , LC , E2000

Fiber mode

Single-mode(G652,G655,G657), multi-mode (50, 62.5, OM2, OM3, OM4)

Fiber cable type

250um ribbon fiber,ribbon cable,Bundle fiber optic cable
