Production Type | Unit | ST | SC | FC | LC | |||||||
PC | UPC | PC | UPC | APC | PC | UPC | APC | PC | UPC | APC | ||
Optic Fiber Type | 9/125, 62.5/125, 50/125 | |||||||||||
Insertion Loss | dB | ≤0.3, typical ≤0.2 | ||||||||||
Return Loss(min.) | dB | ≥45 | ≥50 | ≥45 | ≥50 | ≥65 | ≥45 | ≥50 | ≥65 | ≥45 | ≥50 | ≥65 |
Repeatability | dB | ≤0.1 | ||||||||||
Interchangeability | dB | ≤0.2 | ||||||||||
Operation temp | ℃ | -25 to +70 | -40 to +70 | -25 to +70 | ||||||||
Durability | time | ≥500 | ||||||||||
Customization | MU、E2000、MPO are available |
FTTH
CATV
LAN
Fiber Optic Sensor
Video Transmission
High quality components
Low insertion loss
High return loss
Good exchangeability
Good repeatability
