Product Type | Unit | Standard | Single window | Double window | multi-mode |
Working Wavelength | nm | 1310 or | 1310 or | 1310 and | 850 and 1300 |
1550 | 1550 | 1550 | |||
Bandwidth | nm | ±20 | ±40 | ±40 | |
Uniformity | dB | 0.5 | 0.6 | 0.8 | 0.7 |
Port type | 1×2,2×2,1×3,2×3,3×3,1×4 | ||||
Directionality | dB | ≥55 | |||
Working temperature | ℃ | -40 to +85 | |||
Encapsulation ways | ABS box type (0.9mm, 2.0mm, 3.0mm),Steel tube (250um bare fiber or 0.9mm), LGX box packed. | ||||
CATV
FTTX
Local area network
Optic test system
Network monitoring
Fiber optic sensor
Low insertion loss
Low PDL
High directivity
Compact size
Various coupling ratio
