D×H: φ190×440MM
Cable ports: 4 ports
Cable Diameter: Max φ25
Max.Capacity (bunchy fiber): 96
Core capacity per tray: 12 or 24
Sealing structure: Heat-shrinkable sealing
Operation temperature: -40℃-+60℃
Bending radius: ≥40mm
Pressure resistance: 70-106KPa
Tensile force: 1000N (minimum value)
Strength: 15KV(DC)/min. no flashover
Pressure testing valve and earth deriving device
Integrated seal, air tight and water proof
Ideal for cable repair
ROHS compliant
Can be used in through, branch or mid span splice locations
Suitable for aerial, underground duct or direct burial applications
High strength material
Full components
Easy to maintain and install
Excellent seal performance
Both burying and aerial are available
